Motion Detection 2.0

Human/Vehicle Analysis

Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights;

Quick search by object or event type is supported;

Recording

Video CompressionH.265 Pro/H.265

Encoding Resolution

When 1080p Lite mode is not enabled:

3K Lite/5 MP Lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF;

When 1080p Lite mode is enabled:

3K Lite/5 MP Lite/4 MP Lite/1080p Lite/720p Lite/VGA/WD1/4CIF/CIF

Frame Rate

Main stream:

When 1080p Lite mode not enabled:

For 3K stream access: 3K Lite@12 fps; 4 MP Lite/1080p@15 fps;

720p/WD1/4CIF/VGA/CIF@20 fps

For 5 MP stream access: 5 MP Lite@12fps; 4 MP Lite/1080p@15 fps;

720p/WD1/4CIF/VGA/CIF@20 fps

For 4 MP stream access: 4 MP Lite/1080p@15 fps; 720p/WD1/4CIF/VGA/CIF@25 fps

(P)/30 fps (N)

For 1080p stream access: 1080p/720p@15 fps; VGA/WD1/4CIF/CIF@25 fps (P)/30 fps

(N)

For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

When 1080p Lite mode enabled:

3K Lite/5 MP Lite@12fps; 4 MP Lite@15 fps; 1080p Lite/720p

Lite/VGA/WD1/4CIF/CIF@25 fps (P)/30 fps (N)

*: 3K Lite/5 MP@12 fps is only available for channel 1.

Sub-stream:

WD1/4CIF@12 fps; CIF@25 fps (P)/30 fps (N)

Video BitrateAccording to the actual scene, scene-adaptive bitrate control technology would automatically allocates appropriate bitrate to ensure the stability of recording period.

Stream Type

Video, Video & Audio

Note: In order to protect privacy, the device will only record video (without audio) by default. If you want to record audio, you shall manually enable audio recording. For operation details, refer to the user manual.

Audio CompressionG.711u

Audio Bitrate64 Kbps

Video And Audio

IP Video Input

1-ch

Up to 6 MP resolution

Support H.265+/H.265 IP cameras

Analog Video Input

4-ch

BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI Input5 MP@20 fps, 3K@20 fps, 4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps

AHD Input4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps

HDCVI Input4 MP@30 fps, 4 MP@25 fps, 1080p@30 fps, 1080p@25 fps, 720p@30 fps, 720p@25 fps

CVBS InputSupport

HDMI Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video Output ModeHDMI/VGA simultaneous output

Audio Input4-ch via coaxial cable

Audio Output1-ch via HDMI

Synchronous Playback4-ch

Network

Total Bandwidth

72 Mbps

Incoming bandwidth: 4 Mbps

Remote Connection32

Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS

Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Auxiliary Interface

Capacity

Built-in 512 GB eSSD (480 GB available)

Note:

The device can store about 2 weeks videos for 4-ch analog cameras (default parameters), this estimation is for reference only

USB InterfaceRear panel: 2 × USB 2.0

Alarm In/OutN/A

General

Power Supply12 VDC, 1 A

Consumption≤ 5.4 W (with eSSD)

Working Temperature-10 °C to 45 °C (14 °F to 113 °F)

Working Humidity10% to 90%

Dimension (W × D × H)151 × 121 × 46 mm (5.94 × 4.76 × 1.81 inch)

Weight≤ 0.5 kg (with eSSD, 1.1 lb.)
